FDZ-150 is an all-in-one system that integrates video, data, and RC transmission. max transmission is 200km, interface support Ethernet; Serial； PPM/S.bus；USB, FDZ-150 use AES 128&AES256 encryption and H.264&H.265 video compression&decompression technology， have strong anti-jamming and keep data and video transmission stable.
Product Feature
TDD bi-directional link with video/telemetry/RC
Receiving diversity and dynamic antenna switching
H.264&H.265 video compression&decompression
Low level re-transmission and adaptive frequency hopping
AES 128&AES256 encryption implemented on FPGA
Specifications
Frequency:1.4GHz
Bandwidth: 2.5MHz(uplink) ； 10MHz(downlink)
Power: 150km37dBm/200km 40dBm
Modulation: OFDM
Constellation: BPSK； QPSK； 16QAM
FEC: LDPC(1/2， 2/3， 3/4， 5/6)
Duplex: TDD
Downlink throughput: 2.3Mbps~10Mbps(10MHz)
Uplink throughput: 115200bps
Voltage: 18V~22V
Working temperature: -20°C~50°C
Size: 143.9X122.3X38mm
Weight: 732g(air/ground)
Video Interface: Ethernet; Serial； PPM/S.bus；USB
