ypology

network-based

material (that sth is made of)

Aircraft aluminum alloy, nylon

sizes

104 (L) x 88 (W) x 158 (H) mm

weights

Camera <450g Shock Absorption 120g

power supply

4S-12S 14-60v

operating temperature

-20℃～ 60℃

Control angle (pitch)

-90°～ +45°

Control angle (direction)

360° continuous rotation

Angular jitter

±0.01°

control signal

S-Bus, UART TTL, Network Port

stockpile

Micro SD card

output interface

Network Port, UART Port TTL, S-BUS, Power Supply

operating mode

Direction lock; heading follow; one button down; target tracking

camcorder

monitoring range

4.8～ 48mm

Horizontal field of view

60.2°～ 6.6°

zoom power

10x optical zoom 40x hybrid zoom

Focusing speed

<1S

Video Output Format

1080p, 25 fps

Video Storage Format

4K, 30 fps 3840*2160

transducers

1/2.8 CMOS 846w pixels

Minimum Illumination

Color: 0.01Lux/F1.5 noise ratio ≧ 30d

Black&White: 0.005Lux/F1.5 noise ratio ≧ 20d

Thermal

Sensor

13nm

detector pixels

640*512

Laser Lighting Module

wavelength

850+10nm

laser power

0.85W

Beam angle

7.5°

spot diameter

14m @ 100m

Lighting effective distance

≤230m

Human Eye Safety Level

Class 3B (IEC 60825-1:2014)

laser indication

power (output)

50mw

color

green

Indication Distance

1000m (non-sunny, direct sunlight environment)

Trigger On

support

laser range finder

realm

5～1000 meters (the specific range is related to the use environment)

Operating Current

80 mA (max)

light beam

905nm Pulsed Laser

angle of divergence

3 mrad

Laser pulse frequency

1Hz, 5Hz

power (output)

<1 mW (supports eye safety)

Identification of people and vehicle

support

GPS Location Analysis

Latitude and longitude of the target
